Dual Rail 3+2-Phase PWM Controller with PMBus

Also available as single-rail/6-phase- controller variant; see RTQ8826

• Output voltage range from 0.25V to 1.516V
• Embedded LDO for Dr.MOS 3.3V PWM level
• Current sensing by either current type or voltage type SPS (Smart Power Stage)
• Internal non-volatile memory for storing custom settings
• Programmable timings for power up & down
• V_OUT, I_OUT, and temperature monitoring
• Various fault protection & fault detection functions
• I2C/PMBus control interface

Application area: Power supply for FPGA, ASIC, DSP, SoC

Datasheet: RTQ8825 – Richtek
